PFSM Mini-Step Feeder

“Single-Step” step feeder with 4″ wide step and 200 cu. in. integrated hopper bin. A standard screw escapement package is available, making the PFSM easily integrated into automatic screwdriving applications.

Specifications

• Input: 110, 220 VAC for controls
• Step Materials: Teflon hard coat anodized aluminum, hardened, ground and plated steel
• Step Thicknesses: 3/8″-1/2″, determined by the size of the parts being fed
• Step Width: 4″
• Step Stroke: 5″
• Bin Size: 200 cu. in. capacity
